Melbourne Metro Tunnel: A Revolution in Rail Transportation Set for 2025 Launch

The much-anticipated Melbourne Metro Tunnel is poised to transform the city’s rail network, with an expected opening by the end of 2025. This ambitious project, representing the most significant advancement since the City Loop commenced operations in January 1981, involves the construction of twin tunnels beneath the Melbourne CBD, connecting the western suburb of Sunbury to the southeastern suburbs of Cranbourne and Pakenham. The new line will also provide direct rail access to Parkville and St Kilda Road for the first time. The project includes five new underground stations: Arden, Parkville, State Library, Town Hall, and Anzac, along with crucial connections to existing networks at Flinders Street and Melbourne Central stations. This article delves into the innovative signalling and safety enhancements set to revolutionize Melbourne’s public transport system, examining the challenges and the expected benefits for both commuters and the rail network itself.

Advancing Capacity: The High Capacity Signalling System

A cornerstone of the Metro Tunnel project is the implementation of a new High Capacity Signalling (HCS) system. This system is being delivered by the Rail Network Alliance (RNA), which includes Alstom, a Joint Venture of John Holland and CPB Contractors, AECOM, Metro Trains Melbourne, and the State of Victoria. The HCS system, featuring Alstom’s world-leading Communications-Based Train Control (CBTC) solution known as Urbalis, is installed throughout the twin tunnels and sections of the Cranbourne, Pakenham, and Sunbury lines. This marks the first instance of High Capacity Signalling being deployed on an existing rail network in Australia. Since January 2023, CBTC has been in operation along sections of the Pakenham/Cranbourne line. By wirelessly communicating the exact location of moving trains, the CBTC system allows for dynamic speed adjustments, optimizing train spacing and significantly boosting overall line capacity. The new signalling system enables more frequent services, with trains potentially running every three minutes, and the ability to reduce that time further to two minutes during peak hours.

Pioneering Mixed-Mode Signalling: A Technological Leap

A key technical achievement of the Metro Tunnel project is that it’s the first mixed-mode signalling application in Australia, where Alstom combines CBTC with mainline signalling on the same line. This required careful integration with the existing network, which serves V/Line and freight trains, in addition to the new Metro trains. According to Alexander Robinson, Rail Control and Project Engineering Manager at Alstom, this bespoke system involved “reverse-engineering Victorian signalling principles…and incorporate those rules into modern CBTC signalling technology.” This complex undertaking required a blend of global expertise and local know-how. Alstom brought in international specialists from its Product Centre in Pittsburgh, USA, to collaborate with the Melbourne-based team. The integration and adaptation for the mixed-mode signalling system also frees up space within the City Loop, which will allow for other lines to increase their service capacity.

Enhancing Safety: Platform Screen Doors and Passenger Safety

The Metro Tunnel project also incorporates Platform Screen Door (PSD) technology, a significant enhancement for passenger safety. Installed at all five new underground stations, the PSDs are designed to prevent incidents at the crucial train-platform interface. Alexander Robinson of Alstom highlights that a significant portion of rail safety incidents occur at this location. PSDs bring an extra level of safety by separating passengers from moving trains. Additionally, PSDs contribute to improved punctuality by preventing delays caused by passengers boarding after the doors close or being in contact with the train. To address potential entrapment issues due to the space between the train doors and the PSDs, Alstom has developed a specific design with fins or boxes to fill the gap, ensuring passenger safety at all times. Skylar (Xin) Qi, System Integration Test Engineer at Alstom, confirms rigorous testing procedures, including on-site evaluations and lab-based simulator tests, prioritizing safety above all.

Innovations in Track Maintenance and Operational Efficiency

Alstom’s CBTC solution significantly reduces the amount of wayside equipment required, thus reducing maintenance costs and downtime. Within the tunnel, there is very little trackside equipment. This reduction in infrastructure minimizes the need for track circuits and signal access. This also eliminates the need to shut down the railway line for routine maintenance. The modern CBTC system also provides a wealth of data to maintenance teams, which can be used to optimize maintenance schedules and proactively address potential issues. Alstom is also providing ongoing maintenance support, with a 10-year service agreement with Metro Trains, ensuring system performance and longevity. These initiatives promise increased reliability, consistent runtime, and improved punctuality, even in the event of conventional signalling failures. This will enable nearly 24/7 operation of the trains.

Conclusion

The Melbourne Metro Tunnel project represents a pivotal moment for Melbourne’s public transport system. With the implementation of cutting-edge technologies such as High Capacity Signalling and Platform Screen Doors, the project aims to significantly increase capacity, enhance safety, and improve service reliability. The innovative mixed-mode signalling system, a first for Australia, exemplifies the project’s technological ambitions and its commitment to integrating new technologies with existing infrastructure. The project addresses the growing demand for more efficient and reliable mass transit systems. The Metro Tunnel will provide considerable benefits not just to those along the corridor but also to the broader public transport users in Melbourne. The project’s focus on reducing maintenance requirements and maximizing operational efficiency promises to reshape the economics of rail transport. The expertise of teams like Alstom and Metro Trains Melbourne, will likely set a benchmark for future rail projects in Australia and beyond. The project, slated for completion by the end of 2025, holds great promise for the future of public transport in Melbourne, promising a safer, more efficient, and more connected rail network for commuters.
