This article explores the engineering and logistical challenges overcome in the construction of the South Island Line (East) (SIL(E)), a crucial addition to Hong Kong’s Mass Transit Railway (MTR) network. The project aimed to alleviate traffic congestion in the Aberdeen area, improve travel times between Southern District communities and the city center, and stimulate economic growth in the region. The SIL(E) presented unique difficulties due to the densely populated and geographically challenging terrain. This analysis will delve into the project’s planning stages, construction methodologies, technological innovations employed, and the resulting impact on Hong Kong’s transportation infrastructure. We will examine the route alignment, station design, and integration with existing MTR lines, focusing on the project’s success in balancing technological advancement with environmental considerations and community needs.

Route Alignment and Construction

The SIL(E) project, initially proposed in 2000 as part of the Second Railway Development Study (RDS-2), underwent significant revisions to its route alignment before final approval. The initial proposal proved financially unviable, necessitating several iterations by the MTR Corporation and the Transport Council. The finalized route commences at South Horizons station and terminates at Admiralty station (an existing MTR interchange), traversing through Ocean Park, Wong Chuk Hang, and Lei Tung stations. A key design element involved a combination of underground tunnels and above-ground viaducts, minimizing disruption to existing infrastructure and maximizing the efficient use of space in this densely populated urban environment. The choice of construction methods, such as drill-and-blast for deep rock excavations and cut-and-cover for shallower sections, was crucial for mitigating environmental impact and ensuring safety. The management of excavated materials also required sophisticated logistics, involving temporary barging facilities and a secure explosives magazine.

Station Design and Integration

The SIL(E) stations were designed to integrate seamlessly with the existing MTR network, while also accommodating the unique demands of this new line. The platforms, although shorter (120m long, 15.5m wide) compared to existing MTR stations (260m long, 20.5m wide), were thoughtfully planned to handle the projected passenger load of 20,000 passengers per hour per direction. A mix of underground and at-grade stations (South Horizons, Lei Tung, and Admiralty being underground, and Ocean Park and Wong Chuk Hang being at-grade) was adopted based on the specific geographic and logistical considerations of each location. Admiralty station, a key interchange point, required the construction of two additional platforms below the eastern end to facilitate efficient passenger transfer between lines. The architectural design emphasized integration with the surrounding environment, with careful consideration given to landscaping and harmonious color schemes for the viaduct structures.

Technological Innovations and Sustainability

The SIL(E) project incorporated several technological innovations to improve efficiency and minimize environmental impact. The use of electric trains, running with a headway of 2-4 minutes, represents a commitment to sustainable transportation. The design of the Wong Chuk Hang depot, with its sunken and fully enclosed track, effectively controlled noise pollution during maintenance operations. Furthermore, the Wong Chuk Hang station integrates 12,000 m² of open space above the Staunton Creek Nullah, including a dedicated pet area, demonstrating a commitment to urban greening and community needs. The widening of Heung Yip Road to facilitate a public transport interchange between road and rail highlights the integrated approach to improving overall transportation accessibility.

Project Summary and Conclusion

The South Island Line (East) project stands as a testament to the successful integration of advanced railway technology with meticulous urban planning. The project faced numerous challenges, from navigating complex geological conditions to integrating with the existing MTR infrastructure while minimizing disruption. The project’s success can be attributed to a combination of factors, including careful planning, innovative construction methodologies, and a focus on environmental sustainability. The line’s successful completion has not only provided a significant boost to the Southern District’s connectivity but has also served as a model for future urban rail projects. The integration of open spaces, such as the 12,000 m² area above Wong Chuk Hang Station, showcases a commitment to balancing infrastructure development with community needs. The efficient handling of excavated material and the implementation of safety measures at the temporary explosives magazine highlight the project’s focus on risk management. The reduction of travel times and alleviation of traffic congestion have demonstrably improved the quality of life for residents and spurred economic growth in the region. The SIL(E) project’s success is a strong argument for investing in efficient and sustainable public transport solutions in dense urban environments.

Company Information:

MTR Corporation: Hong Kong’s major public transport operator.

Atkins China: A global engineering and design consultancy.
