Ringsted-Fehmarn Railway Link: Enhancing Scandinavian-European Connectivity

This article explores the Ringsted-Fehmarn railway link, a significant infrastructure project aiming to modernize and enhance rail transport between Scandinavia and continental Europe. The project’s primary goal is to drastically reduce travel times between Copenhagen (Denmark) and Hamburg (Germany), thereby fostering economic growth and improving cross-border connectivity. This will be achieved through a combination of track upgrades, new signaling systems, and the construction of new bridges and overpasses. The anticipated increase in passenger and freight rail traffic will provide a more efficient and environmentally friendly alternative to road transport, contributing significantly to reducing carbon dioxide (CO2) emissions. A key objective is to significantly increase the daily train services between Denmark and Germany, improving both passenger and freight transport capabilities. The following sections will delve into the project’s scope, technical specifications, and anticipated impact.

Project Overview and Scope

The Ringsted-Fehmarn link is a crucial component of the broader initiative to improve rail infrastructure connecting Scandinavia and the European mainland. The project involves significant upgrades to the existing railway line between Ringsted and Fehmarn, focusing on increased capacity and speed. This includes track upgrading to allow for 200 km/h passenger train operation, realignment of curves to improve speed and safety, and the construction of new bridges to replace or enhance existing structures. A considerable element of the project involves the implementation of the European Rail Traffic Management System (ERTMS) Level 2, a modern signalling system designed to improve punctuality and reliability. Electrification of the line at 25 kV AC will also be implemented, enabling electric traction for greater efficiency and reduced environmental impact. The project’s substantial scale requires a coordinated effort among various stakeholders, including Banedanmark (the Danish state-owned railway company), engineering firms, and regulatory bodies in both Denmark and Germany.

Key Infrastructure Improvements

The project encompasses a wide range of infrastructure improvements. These include: track upgrades between Ringsted and Vordingborg for higher-speed passenger trains; realignment of curves and platform relocation at Glumsø station; elimination of level crossings, such as the one at Eskilstrup, through the construction of flyovers; the construction of a new double-track concrete bridge across Masnedsund replacing the existing Bascule Bridge; and the construction of a new bridge south of the King Frederik IX bridge over Guldborgsund. Furthermore, the project involves the addition of passing loops at strategically located stations (Glumsø, Orehoved, and Holeby) to increase line capacity and reduce delays. Finally, significant noise mitigation measures, including facade insulation for approximately 1,700 homes and businesses, are incorporated into the project’s scope.

Signalling and Electrification

The implementation of the ERTMS Level 2 signalling system is a critical aspect of the project. This modern system will enhance the overall safety, reliability and efficiency of the line. It allows for improved train control, reducing delays and increasing the number of trains that can operate on the line. The electrification of the entire Ringsted-Holeby section at 25 kV AC is equally important. This transition from diesel to electric traction will significantly reduce CO2 emissions and improve operational efficiency.

Project Management and Key Players

The project’s success relies on effective project management and collaboration among various stakeholders. Banedanmark (the Danish state-owned railway company) is the primary operator and project manager. Significant design work was undertaken by prominent engineering consultancies, including NIRAS and Rambøll, with further sub-consultancies from ÅF (Sweden), Witteveen & Bos (Netherlands), Ineco (Spain), and LE34. This demonstrates the international collaboration involved in such large-scale infrastructure projects. The timely execution requires close cooperation with regulatory authorities in both Denmark and Germany to ensure compliance with all necessary permits and approvals.

Project Summary Table

Conclusions

The Ringsted-Fehmarn railway link represents a substantial investment in modernizing Scandinavian-European rail infrastructure. The project’s ambitious targets, including increased speed, capacity, and reliability, aim to significantly improve cross-border connectivity. The implementation of ERTMS Level 2 and electrification of the line showcases a commitment to modern technology and environmental sustainability. While the project’s success hinges on effective project management and timely regulatory approvals, the potential benefits are substantial. The projected increase in daily passenger services from six to twenty exemplifies the expected impact on cross-border travel and freight transport. This improved connectivity is expected to boost economic activity in the region, reduce reliance on road transport, and contribute to a reduction in CO2 emissions. The collaborative efforts of Banedanmark, engineering firms such as NIRAS and Rambøll, and various international sub-consultants are crucial to realizing the project’s objectives. The successful completion of this project will serve as a model for future large-scale rail infrastructure development, highlighting the importance of strategic planning, technological innovation, and international cooperation.

Company Information:

• Banedanmark: The Danish state-owned railway infrastructure manager.
• NIRAS: A large international engineering and consulting firm.
• Rambøll: A global engineering, design, and consultancy company.
• ÅF: A Swedish engineering and consulting company.
• Witteveen & Bos: A Dutch engineering and consultancy firm.
• Ineco: A Spanish engineering and consultancy company specializing in transport infrastructure.
• LE34: Information not readily available.
